Erstellt für Generatorgenset - Kutai Automatic Voltage Regulator AVR EA04C VR63-4C

The Kutai Automatic Voltage Regulator AVR EA04C VR63-4C is a high-quality voltage regulator designed for use in generators and gensets. With its advanced sensing input voltage of 160~265 VAC / 300~550 VAC single phase, it offers a powerful solution for regulating and controlling voltage and frequency to ensure consistent power output.

This voltage regulator has a power input of 90~240 VAC single phase and an output voltage of max 32 VDC @ 120 VAC input, max 63 VDC @ 240 VAC input. It can handle a continuous current of 4A and intermittent current of 7A for 60 seconds, with a minimum resistance of 15 Ohm and a maximum of 100 Ohm. The Kutai AVR also has voltage regulation, voltage build-up, and residual voltage at AVR terminal and can easily be externally adjusted with a voltage adjustment of +/- 15% using a 1 K Ohm 1 watt trimmer.

The Kutai AVR has a maximum power dissipation of 8 watt and is equipped with internal electromagnetic interference filtering to reduce noise and enhance performance. The thermal drift is 0.05% per-degree Celsius change in AVR ambient, ensuring that the voltage regulator runs efficiently. It also features under-frequency protection and a U/F Knob of 43~60 Hz and over excitation shutdown. The field volts can shut down after a time delay if the exciter field volts exceed 100 +/- 5 VDC.

This Kutai AVR is suitable for use in harsh environments due to its high durability. It can withstand operating temperatures of -40~60 degrees Celsius and storage temperatures of -40~85 degrees Celsius. It also can operate under relative humidity up to a maximum of 95% and has vibration resistance of 1.5G @ 5~30 Hz and 5.0G @ 30~500 Hz.

Overall, the Kutai Automatic Voltage Regulator AVR EA04C VR63-4C is an excellent choice for those looking for a high-quality voltage regulator for their generators and gensets. With its advanced features and robust design, it offers a reliable solution for regulating and controlling your power output, ensuring consistent performance and protection for your equipment.
