Kompatibel mit SmartGen CMM366-4G Cloud Monitoring Communication Module

Introducing our latest product, the 4G Wireless Genset Monitoring System. This innovative system allows you to connect to a cloud server via a 4G wireless network, providing you with one-to-one monitoring capabilities for your Genset.

One of the key features of this system is its ability to communicate with various Genset control modules. With multiple ports including RS485, RS232, LINK, and USB (Host), it can monitor the majority of Genset control modules from international first-class brands.

Our Genset Monitoring System offers a widely compatible power supply ranging from DC (8~35)V, meaning it can directly use the Genset's built-in battery as a power source. This ensures uninterrupted monitoring even in remote locations.

Powered by an ARM-based 32-bit SCM, this system boasts high integration of hardware and strong programming ability. With its GPS locate function, it can provide accurate location information and help you locate your Genset with ease.

Utilizing the JSON network data communication protocol, our system uploads real-time data variations to the cloud server while efficiently compressing network flow. This reduces data usage and allows for faster and more efficient monitoring. In case of an alarm, the system can immediately upload the data to the server, ensuring timely action can be taken.

The 4G Wireless Genset Monitoring System also features 2 auxiliary digital input ports, which can receive external alarm signals, further enhancing its monitoring capabilities. Additionally, it has 1 auxiliary relay output port that can output various alarm signals, providing you with a comprehensive alarm system.

Designed with convenience in mind, this system includes power and multiple communication status indicators on the front panel. This allows for clear and easy monitoring of its working status at a glance. The system also features a lamp test function, enabling you to efficiently check its functionality.

For ease of use, users can adjust parameters via the USB port, allowing for customization and optimization of the monitoring system.

The module itself is designed for easy installation, with options for standard 羽-type 35mm guide-rail installation or screw-fixed installation in the Genset control box. Its modular design, self-extinguishing ABS plastic shell, lightweight, and compact structure make it an ideal choice for any Genset monitoring application.

Experience the next level of Genset monitoring with our 4G Wireless Genset Monitoring System. Stay connected, stay informed, and stay in control of your Genset's performance.
